M90 Power Mulcher

M90 Power Mulcher

The Reinco M90 PowerMulcher sets the standard for large production sites with bale capacity for twenty tons of hay or straw per hour, and placement of up to 100 feet. The sturdy, two-piece fully adjustable feed tray with hydraulic conveyor system speed mulch delivery to the patented beater drum. Tray adjustments accommodate various bale sizes. The operator has complete control of the mulch delivery and placement. Ten acres or more can be mulched in an hour or less. Combining a half century of experience in this specialized eld, Epic’s commitment to customer service, and with an industry leading two-year power mulcher warranty, your satisfaction can be assured. For years of dependability, demand Reinco PowerMulching machinery!

• 125 hp John Deere Diesel Engine
• 20 Ton Per Hour Mulch Output
• Discharge Distance 100 Feet in Still Air
• Automatic Bale Segmenting
• Variable Speed Hydraulic Feed System
• Standard Heavy Duty Trailer

The fully variable hydraulic feed conveyor system moves the bales to engage the flake separator, flipping the bale segments into the beater chamber. Bale guides and flaker are adjustable for various bale sizes. Average mulch output 20 tons per hour. Boom discharge range in still air is 100 feet.

Proven symmetrically tapered beater drum (thrashing chamber) is designed to improve mulch separation for uniform distribution. Outfitted for supply air scavenging and heavy debris expulsion.

The M90 is a self-contained portable machine consisting of electrically welded modular components secured with plated self- locking fasteners, mounted on a fabricated steel base.

Engine power is reliably transmitted directly via flexible coupling to the blower. Fully adjustable flail stations are mounted in common on the heavy-duty beater shaft. Access for flail adjustment is through hinged drum panel.

Formed cold finish steel discharge boom with center pivot bearing mounts to heavy-duty ball bearing slew assembly for unrestricted 360° horizontal rotation. Formed handle bar with gas charged counter balance spring provides responsive 60° control of vertical placement. Rolling polyurethane top and bottom seals with stainless steel side wipers insure operator comfort.

Extendible two-piece feed tray extends and locks in position to adapt to various tailgate overhangs, then retracts for storage and transport.

Power is provided from a four cylinder, heavy duty water cooled, Tier 3 emissions certified John Deere diesel engine, rated 99HP @ 2400 RPM. 12V ignition, battery, alternator and starter, fuel filter, two-stage dry evacuator type air cleaner, governor and chaff screen are standard. Fuel tank capacity is 30 gallons. Keyed ignition, J1939 CAN LCD graphical display instrumentation offers complete electronic engine monitoring and quick setting, and weatherproof throttle are mounted for operator access. A foot operated signal horn, provides audio signaling for vehicle driver and crew.

Trailer frame offers dual 5200 pound, leaf spring mounted axles, and 15″ 8 ply belted radial tires to comprise the running gear. Adjustable lunette eye draw bar coupler, safety chain, 1000 lb. swing jack, fenders, bumper, DOT recommended lighting, FMVSS vehicle identification and wiring connector to tow vehicle are standard.

Machine primed and then finished with Epic lead free yellow modified acrylic final topcoat. Accessories are furnished plated or finish painted; complete with operating and safety decals.
